Of course! Let's dive deep into scipy.optimize.linprog, the powerful function in SciPy for solving linear programming (LP) problems.

What is Linear Programming?

Linear Programming is a method to achieve the best outcome (like maximum profit or lowest cost) in a mathematical model whose requirements are represented by linear relationships. It's a fundamental technique in operations research, economics, and engineering.

A standard LP problem has the following components:

1. Decision Variables: The quantities you want to determine (e.g., how many of product A and B to produce).
2. Objective Function: A linear equation you want to maximize or minimize (e.g., maximize profit: 3x + 5y).
3. Constraints: A set of linear inequalities or equations that the decision variables must satisfy (e.g., limited labor hours: 2x + 4y <= 100).

The scipy.optimize.linprog Function

scipy.optimize.linprog solves a linear programming problem in the following standard form:

Minimize: cᵀx

Subject to: A_ub x <= b_ub A_eq x = b_eq lb <= x <= ub

Where:

• x is a vector of decision variables (what we're solving for).
• c is a vector of coefficients in the objective function.
• A_ub and b_ub define the inequality constraints (<=).
• A_eq and b_eq define the equality constraints ().
• lb and ub are lower and upper bounds on the decision variables x.

Key Point: SciPy's linprog only solves minimization problems. If you want to maximize a function, you can simply minimize its negative.

Function Signature and Parameters

scipy.optimize.linprog(c, A_ub=None, b_ub=None, A_eq=None, b_eq=None, bounds=None, method='highs', ...)

Let's break down the most important parameters:

Return Value

The function returns an OptimizeResult object, which is a dictionary-like object with several useful attributes:

Practical Examples

Let's work through two common examples.

Example 1: Maximization Problem (A Classic "Product Mix")

A company produces two products, A and B. Product A gives a profit of $3 per unit, and Product B gives a profit of $5 per unit. The production is constrained by two resources:

1. Labor: 100 hours available. Product A takes 2 hours, and Product B takes 4 hours.
2. Materials: 120 kg available. Product A takes 4 kg, and Product B takes 3 kg.

Goal: How many units of A and B should be produced to maximize profit?

Formulate the Math Problem:

• Decision Variables:
  • x = number of units of Product A
  • y = number of units of Product B
• Objective Function (Maximize Profit):
  • P = 3x + 5y
• Constraints:
  • Labor: 2x + 4y <= 100
  • Materials: 4x + 3y <= 120
  • Non-negativity: x >= 0, y >= 0

Convert to SciPy's Standard Form (Minimization):

• We need to minimize -P.
• c = [-3, -5]
• Inequality constraints A_ub x <= b_ub:
  • A_ub = [[2, 4], [4, 3]]
  • b_ub = [100, 120]
• Bounds: x >= 0, y >= 0. We can set this using the bounds parameter.

Python Code:

import numpy as np
from scipy.optimize import linprog
# Coefficients of the objective function (to be minimized)
# We want to maximize P = 3x + 5y, so we minimize -P = -3x - 5y
c = [-3, -5]
 # Coefficients for the inequality constraints (A_ub @ x <= b_ub)
# 2x + 4y <= 100
# 4x + 3y <= 120
A_ub = [[2, 4],
        [4, 3]]
b_ub = [100, 120]
# Bounds for x and y (x >= 0, y >= 0)
# Each tuple is (min, max) for a variable.
# None for max means no upper bound.
bounds = [(0, None), (0, None)]
# Solve the linear programming problem
# 'highs' is the recommended default solver
result = linprog(c, A_ub=A_ub, b_ub=b_ub, bounds=bounds, method='highs')
# Print the results
if result.success:
    print("Optimization successful!")
    print(f"Optimal values (x, y): {result.x}")
    print(f"Maximum Profit: ${-result.fun:.2f}") # Negate the result because we minimized -P
    print("\nConstraint Slack:")
    print(f"Labor constraint slack: {result.slack[0]:.2f} hours")
    print(f"Material constraint slack: {result.slack[1]:.2f} kg")
else:
    print("Optimization failed.")
    print("Message:", result.message)

Output:

Optimization successful!
Optimal values (x, y): [10. 20.]
Maximum Profit: $130.00
Constraint Slack:
Labor constraint slack: 0.00 hours
Material constraint slack: 10.00 kg

Interpretation: The company should produce 10 units of A and 20 units of B for a maximum profit of $130. The labor constraint is fully used (slack is 0), but 10 kg of materials are left over.

Example 2: Problem with Equality and Variable Bounds

Problem: Minimize the function: f(x, y) = x + y Subject to:

1. x + y = 10 (Equality constraint)
2. x >= 2 (Lower bound)
3. y <= 8 (Upper bound)

Formulate for SciPy:

• c = [1, 1]
• Equality constraint A_eq x = b_eq:
  • A_eq = [[1, 1]]
  • b_eq = [10]
• Variable bounds:
  • x: [2, None]
  • y: [None, 8]

Python Code:

import numpy as np
from scipy.optimize import linprog
# Coefficients of the objective function (to be minimized)
c = [1, 1]
# Coefficients for the equality constraint (A_eq @ x == b_eq)
A_eq = [[1, 1]]
b_eq = [10]
# Bounds for x and y
# x >= 2, y <= 8
bounds
