Of course! Here's a comprehensive guide to using QRadioButton in Python with the popular PyQt6 library.

What is a QRadioButton?

A QRadioButton is a standard button that can be either checked or unchecked. It's used to present a user with a set of mutually exclusive options. This means that when you select one radio button in a group, any other previously selected radio button in the same group is automatically deselected.

This "one-of-many" behavior is the key feature that distinguishes radio buttons from regular QPushButton or QCheckBox widgets.

The Basic Example: A Single Group

Let's start with the simplest possible example: a window with three radio buttons for selecting a favorite color.

Code

import sys
from PyQt6.QtWidgets import (
    QApplication,
    QMainWindow,
    QWidget,
    QVBoxLayout,
    QRadioButton,
    QLabel,
)
class MainWindow(QMainWindow):
    def __init__(self):
        super().__init__()
        self.setWindowTitle("QRadioButton Example")
        self.setGeometry(300, 300, 350, 200)
        # --- Central Widget and Layout ---
        central_widget = QWidget()
        self.setCentralWidget(central_widget)
        layout = QVBoxLayout(central_widget)
        # --- Radio Buttons ---
        self.red_radio = QRadioButton("Red")
        self.green_radio = QRadioButton("Green")
        self.blue_radio = QRadioButton("Blue")
        # Add buttons to the layout
        layout.addWidget(self.red_radio)
        layout.addWidget(self.green_radio)
        layout.addWidget(self.blue_radio)
        # --- A label to show the selection ---
        self.result_label = QLabel("Please select a color.")
        layout.addWidget(self.result_label)
        # --- Set a default selection (optional but good practice) ---
        self.green_radio.setChecked(True)
        # --- Connect the 'toggled' signal to our custom slot ---
        # The 'toggled' signal is emitted whenever the check state changes.
        self.red_radio.toggled.connect(self.update_label)
        self.green_radio.toggled.connect(self.update_label)
        self.blue_radio.toggled.connect(self.update_label)
    def update_label(self):
        """This slot is called whenever a radio button is toggled."""
        if self.red_radio.isChecked():
            self.result_label.setText("You selected Red!")
        elif self.green_radio.isChecked():
            self.result_label.setText("You selected Green!")
        elif self.blue_radio.isChecked():
            self.result_label.setText("You selected Blue!")
        else:
            # This case is unlikely with radio buttons in a group,
            # but it's good practice.
            self.result_label.setText("Please select a color.")
if __name__ == "__main__":
    app = QApplication(sys.argv)
    window = MainWindow()
    window.show()
    sys.exit(app.exec())

How to Run

1. Make sure you have PyQt6 installed: pip install PyQt6
2. Save the code as a Python file (e.g., radio_button_example.py).
3. Run it from your terminal: python radio_button_example.py

Output

You will see a window with three radio buttons. Clicking one will highlight it and uncheck the others. The label below will update to reflect your choice.

Key Concepts in the Basic Example:

• QRadioButton("Text"): Creates a radio button with the specified text.
• setChecked(True): Programmatically sets a radio button to be the active one in its group. This is useful for setting a default.
• isChecked(): Returns True if the radio button is currently selected, and False otherwise. This is the most common method for getting the user's choice.
• toggled signal: This signal is emitted every time the button's checked state changes. This is more versatile than clicked because it also fires if the state is changed programmatically (e.g., by another button in the group).
• Signal/Slot Connection: self.red_radio.toggled.connect(self.update_label) links the toggled signal of the red_radio button to the update_label method (our "slot").

Handling Multiple Groups

What if you have two or more independent sets of options? For example, choosing a Size and a Color.

The key is to ensure that radio buttons in different groups do not interfere with each other. The easiest way to do this is to place each group inside its own QButtonGroup.

Code

import sys
from PyQt6.QtWidgets import (
    QApplication, QMainWindow, QWidget, QVBoxLayout, QRadioButton,
    QLabel, QButtonGroup
)
class MainWindow(QMainWindow):
    def __init__(self):
        super().__init__()
        self.setWindowTitle("Multiple Radio Button Groups")
        self.setGeometry(300, 300, 300, 250)
        central_widget = QWidget()
        self.setCentralWidget(central_widget)
        layout = QVBoxLayout(central_widget)
        # --- Group 1: Size ---
        size_label = QLabel("Select Size:")
        layout.addWidget(size_label)
        self.small_radio = QRadioButton("Small")
        self.medium_radio = QRadioButton("Medium")
        self.large_radio = QRadioButton("Large")
        layout.addWidget(self.small_radio)
        layout.addWidget(self.medium_radio)
        layout.addWidget(self.large_radio)
        # Create a QButtonGroup for the size options
        self.size_group = QButtonGroup(self)
        self.size_group.addButton(self.small_radio)
        self.size_group.addButton(self.medium_radio)
        self.size_group.addButton(self.large_radio)
        # Set a default for the first group
        self.medium_radio.setChecked(True)
        # --- Group 2: Color ---
        color_label = QLabel("Select Color:")
        layout.addWidget(color_label)
        self.red_radio = QRadioButton("Red")
        self.green_radio = QRadioButton("Green")
        layout.addWidget(self.red_radio)
        layout.addWidget(self.green_radio)
        # Create a QButtonGroup for the color options
        self.color_group = QButtonGroup(self)
        self.color_group.addButton(self.red_radio)
        self.color_group.addButton(self.green_radio)
        # Set a default for the second group
        self.red_radio.setChecked(True)
        # --- Result Label ---
        self.result_label = QLabel("Your selection: Medium, Red")
        layout.addWidget(self.result_label)
        # --- Connect the buttonGroup's buttonClicked signal ---
        # This signal is more efficient as it gives us the button that was clicked.
        self.size_group.buttonClicked.connect(self.update_selection)
        self.color_group.buttonClicked.connect(self.update_selection)
    def update_selection(self, button):
        """This slot is called when any button in a group is clicked."""
        # Find the ID of the checked button in each group
        size_id = self.size_group.checkedId()
        color_id = self.color_group.checkedId()
        # Map IDs to readable names
        size_map = {self.small_radio.id(): "Small", self.medium_radio.id(): "Medium", self.large_radio.id(): "Large"}
        color_map = {self.red_radio.id(): "Red", self.green_radio.id(): "Green"}
        size_text = size_map.get(size_id, "None")
        color_text = color_map.get(color_id, "None")
        self.result_label.setText(f"Your selection: {size_text}, {color_text}")
if __name__ == "__main__":
    app = QApplication(sys.argv)
    window = MainWindow()
    window.show()
    sys.exit(app.exec())

Output

Now you have two independent sets of radio buttons. Changing the size does not affect the color selection, and vice-versa.

Key Concepts for Multiple Groups:

• QButtonGroup: This class is a container that groups radio buttons together. It ensures that only one button in the group can be checked at a time.
• buttonClicked(button) signal: This signal from QButtonGroup is very useful. It's emitted when a button in the group is clicked, and it passes the specific QRadioButton object that was clicked as an argument. This makes your slot code cleaner.
• buttonGroup.addButton(button): Adds a button to the group.
• buttonGroup.checkedId(): Returns a unique integer ID for the currently checked button in the group. You can assign your own IDs using addButton(button, id) or use the default ones.

Advanced: Using a QButtonGroup with a QGridLayout

For a more organized layout, you can use a QGridLayout and still manage your radio buttons with a QButtonGroup. This is perfect for creating things like option panels or settings dialogs.

Code

import sys
from PyQt6.QtWidgets import (
    QApplication, QMainWindow, QWidget, QGridLayout, QRadioButton,
    QLabel, QButtonGroup
)
class MainWindow(QMainWindow):
    def __init__(self):
        super().__init__()
        self.setWindowTitle("QRadioButton in Grid Layout")
        self.setGeometry(300, 300, 400, 300)
        central_widget = QWidget()
        self.setCentralWidget(central_widget)
        layout = QGridLayout(central_widget) # Use QGridLayout
        # --- Radio Buttons ---
        self.option1_radio = QRadioButton("Option 1")
        self.option2_radio = QRadioButton("Option 2")
        self.option3_radio = QRadioButton("Option 3")
        self.option4_radio = QRadioButton("Option 4")
        # Add buttons to the grid
        layout.addWidget(self.option1_radio, 0, 0)
        layout.addWidget(self.option2_radio, 0, 1)
        layout.addWidget(self.option3_radio, 1, 0)
        layout.addWidget(self.option4_radio, 1, 1)
        # --- A label to show the selection ---
        self.result_label = QLabel("No option selected.")
        layout.addWidget(self.result_label, 2, 0, 1, 2) # Span 2 columns
        # --- Group the buttons ---
        self.options_group = QButtonGroup(self)
        self.options_group.addButton(self.option1_radio)
        self.options_group.addButton(self.option2_radio)
        self.options_group.addButton(self.option3_radio)
        self.options_group.addButton(self.option4_radio)
        # Set a default
        self.option2_radio.setChecked(True)
        # --- Connect the signal ---
        self.options_group.buttonClicked.connect(self.on_option_selected)
    def on_option_selected(self, button):
        """Slot called when an option is selected."""
        self.result_label.setText(f"Selected: {button.text()}")
if __name__ == "__main__":
    app = QApplication(sys.argv)
    window = MainWindow()
    window.show()
    sys.exit(app.exec())

Output

This creates a 2x2 grid of radio buttons. Clicking any one will deselect the others and update the label.

Summary of Key Methods and Signals
