Of course! Here's a comprehensive guide to using JSON-RPC in Java, covering popular libraries, a complete code example, and best practices.

What is JSON-RPC?

JSON-RPC (Remote Procedure Call) is a stateless, lightweight remote procedure call protocol. It uses JSON for data encoding and typically works over HTTP. A JSON-RPC request is a single JSON object with a few key fields:

• jsonrpc: The protocol version, usually "2.0".
• method: The name of the method to be invoked on the server.
• params: An array or object containing the parameters for the method.
• id: A request identifier that can be used to match the response with the request.

A successful response looks like this:

{
  "jsonrpc": "2.0",
  "result": "The result of the method",
  "id": 1
}

An error response looks like this:

{
  "jsonrpc": "2.0",
  "error": {
    "code": -32601,
    "message": "Method not found"
  },
  "id": 1
}

Popular Java Libraries for JSON-RPC

There are several excellent libraries for implementing JSON-RPC in Java. Here are the most popular ones:

For this guide, we'll focus on jsonrpc4j as it's the most general-purpose and easiest to get started with for standard applications.

Step-by-Step Guide with jsonrpc4j

This example will show you how to create a simple JSON-RPC server and a client in plain Java.

Step 1: Add Dependencies

You need to add the jsonrpc4j library to your project. If you're using Maven, add this to your pom.xml:

<dependency>
    <groupId>com.github.briandilley.jsonrpc4j</groupId>
    <artifactId>jsonrpc4j</artifactId>
    <version>1.6.0</version> <!-- Check for the latest version -->
</dependency>

If you're using Gradle, add this to your build.gradle:

implementation 'com.github.briandilley.jsonrpc4j:jsonrpc4j:1.6.0' // Check for the latest version

Step 2: Create the Server

The server consists of two parts:

1. A service interface defining the available methods.
2. A class implementing that interface.

1. Define the Service Interface

This interface declares the methods that can be called remotely. It's good practice to use @JsonRpcMethod annotations to explicitly define the JSON-RPC method name.

import com.github.briandilley.jsonrpc4j.JsonRpcMethod;
public interface MyService {
    /**
     * A simple method that takes a name and returns a greeting.
     * @param name The name to greet.
     * @return A greeting string.
     */
    @JsonRpcMethod("greeting")
    String sayHello(String name);
    /**
     * A method that takes two numbers and returns their sum.
     * @param a The first number.
     * @param b The second number.
     * @return The sum of a and b.
     */
    @JsonRpcMethod("add")
    int add(int a, int b);
}

2. Implement the Service

Now, create a plain Java class that implements the interface.

public class MyServiceImpl implements MyService {
    @Override
    public String sayHello(String name) {
        return "Hello, " + name + "!";
    }
    @Override
    public int add(int a, int b) {
        return a + b;
    }
}

3. Create and Start the Server

jsonrpc4j provides a JsonRpcServer class that can wrap your service implementation. We'll use a simple HttpServer from the Java standard library to handle HTTP requests.

import com.github.briandilley.jsonrpc4j.JsonRpcServer;
import com.sun.net.httpserver.HttpServer;
import java.io.IOException;
import java.net.InetSocketAddress;
public class JsonRpcServerStarter {
    public static void main(String[] args) throws IOException {
        // 1. Create the service implementation
        MyService myService = new MyServiceImpl();
        // 2. Create the JSON-RPC server, wrapping the service
        JsonRpcServer jsonRpcServer = new JsonRpcServer(myService, MyService.class);
        // 3. Create a standard Java HttpServer
        HttpServer server = HttpServer.create(new InetSocketAddress(8080), 0);
        // 4. Create a context to handle all incoming requests at /rpc
        server.createContext("/rpc", exchange -> {
            // Handle preflight OPTIONS requests for CORS
            if ("OPTIONS".equals(exchange.getRequestMethod())) {
                exchange.getResponseHeaders().add("Access-Control-Allow-Origin", "*");
                exchange.getResponseHeaders().add("Access-Control-Allow-Methods", "POST, GET, OPTIONS");
                exchange.getResponseHeaders().add("Access-Control-Allow-Headers", "Content-Type");
                exchange.sendResponseHeaders(204, -1); // No content for OPTIONS
                return;
            }
            // 5. Handle the JSON-RPC request
            if ("POST".equals(exchange.getRequestMethod())) {
                // Set CORS headers for the actual response
                exchange.getResponseHeaders().add("Access-Control-Allow-Origin", "*");
                exchange.getResponseHeaders().add("Content-Type", "application/json");
                // Get the request body
                String requestBody = new String(exchange.getRequestBody().readAllBytes());
                // Process the request using the jsonRpcServer
                String jsonResponse = jsonRpcServer.handle(requestBody);
                // Send the response
                exchange.sendResponseHeaders(200, jsonResponse.getBytes().length);
                exchange.getResponseBody().write(jsonResponse.getBytes());
                exchange.getResponseBody().close();
            } else {
                exchange.sendResponseHeaders(405, -1); // Method Not Allowed
            }
        });
        // 6. Start the server
        server.start();
        System.out.println("JSON-RPC Server started on http://localhost:8080/rpc");
    }
}

Step 3: Create the Client

The client will send JSON-RPC requests to the server. We'll use jsonrpc4j's JsonRpcClient to make this easy.

import com.github.briandilley.jsonrpc4j.JsonRpcClient;
import com.github.briandilley.jsonrpc4j.JsonRpcTransportException;
import java.io.IOException;
import java.net.URI;
import java.net.http.HttpClient;
import java.net.http.HttpRequest;
import java.net.http.HttpResponse;
import java.util.HashMap;
import java.util.Map;
public class JsonRpcClientExample {
    public static void main(String[] args) {
        // The URL of our JSON-RPC server
        String serviceUrl = "http://localhost:8080/rpc";
        // We need a custom transport for the client since jsonrpc4j doesn't have one built-in
        // for Java's HttpClient. We'll create a simple one.
        JsonRpcTransport transport = new JsonRpcTransport(serviceUrl);
        // Create the client
        JsonRpcClient client = new JsonRpcClient(transport);
        // --- Make a request to the 'greeting' method ---
        Map<String, Object> greetingParams = new HashMap<>();
        greetingParams.put("name", "Alice");
        try {
            // The second argument is the expected return type
            String greetingResponse = client.invoke("greeting", greetingParams, String.class);
            System.out.println("Greeting Response: " + greetingResponse);
            // --- Make a request to the 'add' method ---
            Map<String, Object> addParams = new HashMap<>();
            addParams.put("a", 15);
            addParams.put("b", 27);
            Integer addResponse = client.invoke("add", addParams, Integer.class);
            System.out.println("Add Response: " + addResponse);
        } catch (JsonRpcTransportException e) {
            System.err.println("Transport error: " + e.getMessage());
        } catch (IOException e) {
            System.err.println("IO error: " + e.getMessage());
        }
    }
    /**
     * A simple custom transport implementation using Java 11+ HttpClient.
     */
    static class JsonRpcTransport implements com.github.briandilley.jsonrpc4j.JsonRpcTransport {
        private final String serviceUrl;
        private final HttpClient httpClient = HttpClient.newHttpClient();
        public JsonRpcTransport(String serviceUrl) {
            this.serviceUrl = serviceUrl;
        }
        @Override
        public String invoke(String request) throws IOException {
            HttpRequest httpRequest = HttpRequest.newBuilder()
                    .uri(URI.create(serviceUrl))
                    .header("Content-Type", "application/json")
                    .POST(HttpRequest.BodyPublishers.ofString(request))
                    .build();
            HttpResponse<String> response = httpClient.send(httpRequest, HttpResponse.BodyHandlers.ofString());
            return response.body();
        }
    }
}

How to Run the Example

1. Start the Server: Run the JsonRpcServerStarter class. You will see the message: JSON-RPC Server started on http://localhost:8080/rpc.
2. Run the Client: Run the JsonRpcClientExample class.

Expected Output from the Client:

Greeting Response: Hello, Alice!
Add Response: 42

Advanced Topics & Best Practices

Integrating with Spring Framework

jsonrpc4j has excellent Spring support. You can expose a service as a JSON-RPC endpoint with a simple annotation.

// 1. Your service implementation (no change needed)
@Service
public class MySpringServiceImpl implements MyService {
    // ... same methods as before
}
// 2. Create a controller to handle HTTP requests
@RestController
public class JsonRpcController {
    private final MyService myService;
    private final JsonRpcServer jsonRpcServer;
    @Autowired
    public JsonRpcController(MyService myService) {
        this.myService = myService;
        // The server can be a singleton bean
        this.jsonRpcServer = new JsonRpcServer(myService, MyService.class);
    }
    @PostMapping("/rpc")
    public String handleJsonRpcRequest(@RequestBody String json) {
        // Spring automatically handles CORS headers with @CrossOrigin
        return jsonRpcServer.handle(json);
    }
}

This is much cleaner and leverages Spring's dependency injection and web capabilities.

Error Handling

• Server-Side Errors: If your service method throws an exception, jsonrpc4j will automatically catch it and convert it into a standard JSON-RPC error response with code -32000 (Internal Error) and the exception message.
• Client-Side Errors: The client.invoke(...) method can throw JsonRpcException (or more specific transport exceptions) if the server returns an error response. You should wrap your client calls in try-catch blocks to handle these gracefully.

Security

• Authentication: JSON-RPC itself doesn't define an authentication mechanism. You must implement it at the web server level (e.g., using Spring Security, basic auth, or JWT tokens in the HTTP headers).
• HTTPS: Always use HTTPS in production to encrypt the communication between the client and server, preventing data tampering and eavesdropping.
• Input Validation: Never trust client input. Validate all parameters received by your server-side methods to prevent injection attacks or unexpected behavior. Libraries like Hibernate Validator are excellent for this.
